Product Name: High Speed Light Gauge Steel Framing Machine | PLC Control Metal Stud Roll Former with Servo Motor
The High Speed Light Gauge Steel Framing Machine is a premium, next-generation production line engineered for the rapid and precise manufacturing of light steel studs and tracks. Distinguished by its advanced servo motor technology and intelligent PLC control system, this roll former delivers exceptional forming speeds and ultra-accurate cutting lengths. It is the ultimate solution for high-volume manufacturers producing metal framing components for residential, commercial, and industrial drywall construction systems.
- Servo Motor Precision Control: Equipped with a high-performance servo motor for the feeding and cutting mechanisms, ensuring ultra-precise length accuracy, smooth acceleration, and high-speed response without compromising quality.
- Intelligent PLC & HMI Interface: Features a state-of-the-art PLC with a user-friendly touch screen, allowing for easy parameter setup, automatic batch counting, and real-time production monitoring.
- High-Speed Continuous Production: Optimized mechanical structure and high-efficiency gear-motor drive system enable significantly faster forming speeds compared to standard models, maximizing daily output and profitability.
- Integrated Hydraulic Punching System: Built-in automatic punching units accurately create service holes, screw dimples, and mounting slots on the fly, perfectly synchronized with the forming speed.
- Flying Cut-Off Technology: The servo-driven flying shear cuts profiles to exact lengths while the machine is in motion, eliminating the need to stop the line and drastically reducing cycle times.
- Robust & Wear-Resistant Rollers: Forming rollers are machined from high-grade bearing steel and treated with chrome plating and vacuum quenching to ensure a long lifespan and maintain strict dimensional tolerances.
This high-speed machine is ideal for large-scale production of light gauge steel framing, including:
- C-type metal studs and U-type tracks for drywall partitions
- Load-bearing and non-load-bearing wall framing
- Suspended ceiling grids and furring channels
- Prefabricated steel villas and modular construction components
- Warranty: Comprehensive warranty for the entire machine (excluding consumable parts).
- Overseas Installation & Training: Professional engineers dispatched to your facility for installation, debugging, and comprehensive operator training.
- Technical Support: Round-the-clock online troubleshooting and lifelong maintenance guidance.
- Spare Parts Guarantee: Long-term supply of original spare parts, servo components, and custom roller molds at competitive factory prices.
