Product Overview
The Tricycle Carriage Plate Forming Equipment is a specialized, high-efficiency manufacturing system designed exclusively for the three-wheeled vehicle and light cargo transport industry. Engineered to produce premium, one-piece bottom boards, this advanced roll forming machine seamlessly transforms steel coils into structurally superior, seamless carriage floors. By integrating precision roll forming, automated punching, and continuous cutting into a single streamlined production line, it eliminates the need for welding multiple panels. This one-piece bottom board roll forming machine is the ultimate turnkey solution for tricycle and light truck manufacturers seeking to maximize structural integrity, reduce assembly labor, and meet the high-volume demands of the urban logistics and agricultural transport markets.
- One-Piece Seamless Bottom Board Forming: The standout feature of this equipment is its ability to produce a complete, one-piece carriage bottom board with integrated side folds and drainage channels. This seamless design eliminates welding joints, significantly enhancing the structural rigidity, load-bearing capacity, and waterproof performance of the tricycle carriage.
- High-Precision Roll Forming Stations: Engineered with meticulously calibrated, heavy-duty forming stations, the machine ensures that every one-piece bottom board features uniform folds, crisp edges, and exact dimensional tolerances. The premium-grade, hard-chromed rollers guarantee flawless surface quality and consistent geometry for perfect fitment during vehicle assembly.
- Integrated Automatic Hydraulic Punching: Designed for manufacturing efficiency, the system includes a high-speed hydraulic punching unit that automatically creates precise mounting holes, bolt holes, and drainage openings directly during the forming process. The punching positions are fully programmable via the PLC, eliminating secondary drilling and drastically reducing production time.
- Continuous High-Speed Cutting System: Equipped with a robust hydraulic flying shear mechanism, the machine dynamically tracks the moving board to execute clean, burr-free cuts at exact lengths without stopping the production line. This continuous cutting technology maximizes throughput and ensures seamless, high-speed manufacturing of carriage plates.
- Intelligent PLC Automation: Governed by a cutting-edge Programmable Logic Controller (PLC) and a user-friendly touchscreen HMI, the machine automates the entire workflow. Operators can effortlessly set board lengths, batch quantities, and punching parameters. The intelligent system ensures high repeatability, automated length counting, and rapid recipe switching.
- Heavy-Duty Structural Frame & Material Versatility: Built with a reinforced steel chassis to absorb intense forming forces, the machine guarantees stable, continuous operation. It is specifically optimized for processing high-strength galvanized steel, color steel, and aluminum coils, with smooth roller surfaces that protect protective coatings from scratching, ensuring superior corrosion resistance.
The high-precision, one-piece bottom boards produced by this machine are essential components across the light transport and agricultural sectors, including:
- Electric & Gas Tricycles: Manufacturing durable, seamless carriage floors for cargo tricycles, delivery trikes, and passenger tuk-tuks widely used in urban and rural transport.
- Light Commercial Vehicles: Producing structurally superior, one-piece bottom plates for mini-trucks, light cargo carriers, and neighborhood electric vehicles (NEVs).
- Agricultural & Farm Transport: Supplying heavy-duty, impact-resistant carriage bottoms for agricultural trailers, farm carts, and livestock transport tricycles.
- Logistics & Last-Mile Delivery: Creating lightweight, high-strength, and waterproof carriage floors for parcel delivery tricycles and urban logistics fleets.






♦ COMPANY PROFILE:
Hebei Xinnuo Roll Forming Machine Co., Ltd., not only produce different types of professional roll forming machines, but also develop intelligent automatic roll forming production lines, C&Z shape purline machines, highway guardrail roll forming machine lines, sandwich panel production lines, decking forming machines, light keel machines, shutter slat door forming machines, downpipe machines, gutter machines, etc.
There are several advantages of using roll forming for your projects:
- The roll forming process allows operations such as punching, notching, and welding to be performed in-line. Labor cost and time for secondary operations are reduced or eliminated, reducing part costs.
- Roll form tooling allows for a high degree of flexibility. A single set of roll form tools will make almost any length of the same cross-section. Multiple sets of tools for varying length parts are not required.
- It can provide better dimensional control than other competing metal forming processes.
- Repeatability is inherent in the process, allowing easier assembly of roll formed parts into your finished product, and minimizing problems due to “standard” tolerance build up.
- Roll forming is typically a higher speed process.
- Roll forming offers customers a superior surface finish. This makes roll forming an excellent option for decorative stainless steel parts or for parts requiring a finish such as anodizing or powder coating. Also, texture or pattern can be rolled into the surface during forming.
- Roll forming utilizes material more efficiently than other competing processes.
- Roll formed shapes can be developed with thinner walls than competing processes
In modern construction and manufacturing, the roll forming machine (commonly known as a roof tile or sheet metal roll former) has revolutionized profile fabrication. By replacing labor-intensive traditional press brake methods, advanced roll forming technology offers unmatched efficiency, quality, and cost savings for metal roofing and wall panel production.
Here are the key advantages of implementing a modern roll forming machine in your operations:
1. Unmatched High Efficiency and Output Speed
High-speed roll forming lines operate continuously, producing custom metal panels at speeds up to 20–40 meters per minute. This automated process significantly shortens lead times and accelerates project delivery cycles.
2. High Precision and Consistent Quality
Engineered with heavy-duty steel frames, high-precision roller dies, and PLC automated control systems, roll formers deliver pinpoint dimensional accuracy. Every panel exhibits uniform thickness, sharp profiles, and precise hole punching, ensuring seamless job-site installation.
3. Material Efficiency and Reduced Waste
Continuous roll forming minimizes scrap metal generation compared to conventional stamping. Precise coil feeding and automated hydraulic flying shears ensure optimal material utilization and reduced raw material costs.
4. Low Maintenance and Extended Durability
Constructed with heat-treated chrome-plated rollers and robust drive systems, industrial roll forming machines require minimal downtime while delivering a long service life under heavy daily operation.
Conclusion
Investing in a reliable roll forming machine boosts productivity, lowers labor costs, and guarantees consistent product quality—delivering maximum long-term return on investment (ROI) for metal fabrication businesses.
Metal roll forming is a continuous, automated metal fabrication process used to shape long strips of sheet metal (usually coiled steel or aluminum) into specific, uniform cross-sectional profiles.
Unlike traditional metal bending techniques like press braking—which shapes sheets batch by batch—roll forming operates as a continuous production line, making it one of the most efficient manufacturing methods for structural profiles, roofing panels, and automotive components.
How the Metal Roll Forming Process Works
The process passes coil stock through a series of consecutive roller dies to incrementally shape the metal into a finished cross-section:
-
Uncoiling: A heavy coil of sheet metal (often pre-painted, galvanized, or stainless steel) is mounted onto a decoiler and fed continuously into the line.
-
Progressive Forming: The strip passes through a sequence of mating roller stations (known as flower patterns). Each set of rollers gradually bends the metal by a few degrees. By making incremental bends, the process avoids overstressing the material or cracking protective coatings.
-
In-Line Processing (Optional): Pre-punching, post-punching, slitting, or embossing can be integrated directly into the automated line before or after forming.
-
Cutting to Length: Once the final profile is shaped, an automated flying shear or hydraulic cutter cuts the continuous panel into precise custom lengths without interrupting the line speed.
Key Advantages of Metal Roll Forming
-
Continuous High Output: Roll forming lines operate at high speeds (typically 20–50 meters per minute), significantly outperforming press brakes for mass production.
-
Tight Dimensional Tolerances: Advanced PLC automation and precision-machined rollers ensure strict dimensional consistency across every piece produced.
-
Material & Cost Efficiency: Minimizes scrap metal waste and eliminates extra handling steps by integrating punching, bending, and cutting into a single automated line.
-
Design Flexibility & Surface Protection: Capable of producing complex, multi-bend profiles while preserving surface finishes, galvanization, and paint coats.
Common Applications
Metal roll forming is widely used across multiple heavy-duty industries:
| Industry | Common Roll-Formed Products |
| Building & Construction | Trapezoidal roof tiles, standing seam panels, C/Z purlins, drywall studs, rain gutters |
| **Automotive &# What is Metal Roll Forming? |
Metal roll forming is a continuous, high-volume manufacturing process that bends long strips of sheet metal—usually coiled steel or aluminum—into custom cross-sectional profiles.
Unlike traditional press braking or stamping, which processes metal in single discrete batches, roll forming shapes metal incrementally at room temperature (cold forming) through a series of consecutive roller dies.
How Metal Roll Forming Works
The roll forming process relies on a line of paired roller stations that gradually shape the metal in steps:
-
Coil Unloading & Uncoiling: A heavy coil of flat metal strip is loaded onto an uncoiler and fed continuously into the machine.
-
In-Line Pre-Punching: Automatic presses notch, punch holes, or create slots in the flat strip prior to shaping.
-
Progressive Roll Shaping: The strip passes through multiple sets of upper and lower rollers (called roll stations). Each station bends the metal slightly more than the previous one, preventing stress fractures and material strain.
-
Cutting & Shearing: A flying hydraulic shear cuts the finished profile to exact target lengths without stopping the continuous line.
Key Benefits of Roll Forming
-
High Speed & Efficiency: Lines operate at speeds up to 20–50 meters per minute with minimal manual labor required.
-
Consistent Quality & Precision: Heavy-duty tool steel rollers controlled by PLC automation ensure exact tolerances across thousands of identical panels.
-
Material Waste Reduction: Continuous coil processing generates virtually zero scrap compared to conventional sheet stamping or trimming.
-
Complex Profiles: Produces intricate shapes—such as standing seam panels, hat channels, C/Z purlins, and tubular sections—in a single continuous pass.
Common Applications
-
Building & Construction: Roof tiles, wall cladding panels, gutters, structural purlins, and steel framing studs.
-
Automotive: Bumper beams, door impact bars, and chassis structural rails.
-
Solar & Energy: Solar panel mounting racks and support structures.
-
Storage & Industrial: Warehouse racking systems, shelving, and heavy-duty tracks.
-
