Arc Single Board Forming Machine – New Product Description
As a professional automatic processing equipment for arc single board forming, our product is committed to providing efficient and precise solutions for plate bending processing in various industries. Different from traditional forming equipment, it combines intelligent control, high-efficiency forming and multi-scene adaptation, which can quickly convert flat plates into high-quality arc single boards with stable performance, thus helping enterprises improve production efficiency, optimize product quality and enhance market competitiveness.
This arc single board forming machine is designed with a humanized and practical concept, covering all core needs of arc processing. It not only solves the problems of low efficiency, poor precision and easy deformation of traditional processing, but also has the advantages of energy saving, environmental protection, simple operation and strong versatility, making it an indispensable core equipment for modern plate processing enterprises.
Key Features & Highlights
• High-Precision Forming, Stable Quality
Adopting advanced PLC intelligent control system and precision positioning technology, the forming error is controlled within a minimal range, ensuring that each arc single board has smooth lines, flat surface and no defects such as wrinkles, cracks or rebound. The detachable and replaceable forming molds and press rolls can be customized according to different radii and specifications, meeting the diversified processing needs of different products and improving the utilization rate of equipment.
• Efficient Production, Cost-Saving & Profit-Increasing
Equipped with advanced hot pressing or hydraulic forming technology, the equipment can complete the forming and shaping of single boards in a few minutes, which is 10 times more efficient than the traditional cold pressing process that takes 5-6 hours. The automatic feeding, automatic board in/out and one-key operation design greatly reduce manual intervention, only 1-2 workers are needed to complete the whole production process, which significantly reduces labor costs and labor intensity. In addition, the energy-saving motor and heating system effectively reduce energy consumption, and no toxic and harmful substances are discharged during production, complying with green production standards.
• Wide Adaptability, Multi-Scene Application
It is compatible with a variety of plate materials, including solid wood veneer, wood veneer, MDF, resin board, aluminum veneer, ecological board, ceramic insulation board, etc., suitable for plate thickness of 0.3-1500mm and maximum processing length of 2900mm (customizable for longer size). It can not only process simple arc single boards, but also realize the forming of complex shapes such as hyperboloid and special-shaped arcs, widely used in furniture customization, architectural decoration, industrial manufacturing and other fields.
• Durable Structure, Worry-Free Use
The machine body is made of high-strength steel through integral welding, with stable structure, strong load-bearing capacity, smooth operation and low noise, which can work continuously for a long time. All core components are made of high-quality precision parts, which have undergone strict testing and heat treatment, with strong wear resistance, corrosion resistance and long service life. The complete safety protection system (emergency stop, limit protection, overload protection) effectively ensures the safety of operators and equipment operation. Professional after-sales team provides one-stop service including installation, commissioning, training and maintenance, solving all worries for customers.
Technical Parameters (Standard Model, Customizable)
|
Parameter
|
Standard Specification
|
Note
|
|
Rated Power
|
3-5KW
|
Customizable by model
|
|
Rated Voltage
|
380V 50Hz
|
Industrial standard
|
|
Overall Dimension
|
1250*2500*1500mm-4600*1300*1200mm
|
Depends on model
|
|
Overall Weight
|
1299-2100kg
|
Varie with configuration
|
|
Max Processing Length
|
2900mm
|
Longer size available
|
|
Max Processing Thickness
|
0.3-1500mm
|
Suitable for multi-materials
|
|
Feeding Speed
|
8-10m/min
|
Adjustable
|
Application Fields
This arc single board forming machine is widely used in various industries that need arc plate processing, mainly including:
- Furniture Industry: Processing of curved door panels, cabinet doors, sofa armrests, bed heads, office furniture and musical instrument bending parts, suitable for whole-house customization and high-end furniture production.
- Architectural Decoration: Production of interior doors, door casings, wall panels, roof arc decorations, curtain wall arc single boards, helping to create fashionable and elegant decoration effects.
- Industrial Manufacturing: Arc forming of ship shells, chemical equipment cylinders, aluminum profiles, fire doors, building formwork and invisible doors, meeting the processing needs of industrial components.
- Other Fields: Customized processing of special arc single boards for cross-border export, engineering construction and other scenarios, providing personalized solutions for customers.
Product Value
Our arc single board forming machine takes “intelligence, efficiency, precision and environmental protection” as the core, breaks through the limitations of traditional processing technology, and provides cost-effective solutions for plate processing enterprises. It not only improves production efficiency and product quality, but also reduces production costs and enhances enterprise competitiveness. Whether you are a small and medium-sized processing plant or a large-scale manufacturing enterprise, whether you need mass production or high-end customization, this equipment can perfectly meet your needs, helping you seize market opportunities and achieve sustainable development.
♦ COMPANY PROFILE:
Hebei Xinnuo Roll Forming Machine Co., Ltd., not only produce different types of professional roll forming machines, but also develop intelligent automatic roll forming production lines, C&Z shape purline machines, highway guardrail roll forming machine lines, sandwich panel production lines, decking forming machines, light keel machines, shutter slat door forming machines, downpipe machines, gutter machines, etc.
Advantages of Roll Forming A Metal Part
There are several advantages of using roll forming for your projects:
- The roll forming process allows operations such as punching, notching, and welding to be performed in-line. Labor cost and time for secondary operations are reduced or eliminated, reducing part costs.
- Roll form tooling allows for a high degree of flexibility. A single set of roll form tools will make almost any length of the same cross-section. Multiple sets of tools for varying length parts are not required.
- It can provide better dimensional control than other competing metal forming processes.
- Repeatability is inherent in the process, allowing easier assembly of roll formed parts into your finished product, and minimizing problems due to “standard” tolerance build up.
- Roll forming is typically a higher speed process.
- Roll forming offers customers a superior surface finish. This makes roll forming an excellent option for decorative stainless steel parts or for parts requiring a finish such as anodizing or powder coating. Also, texture or pattern can be rolled into the surface during forming.
- Roll forming utilizes material more efficiently than other competing processes.
- Roll formed shapes can be developed with thinner walls than competing processes
Roll forming is a continuous process which converts sheet metal into an engineered shape using consecutive sets of mated rolls, each of which makes only incremental changes in the form. The sum of these small changes in form is a complex profile.
