Trapezoidal Single Board Computer Product Description
The Trapezoidal Single Board Computer (SBC) is a high-performance, integrated embedded computing solution designed with a trapezoidal structural design, combining compact size, robust performance and flexible expandability. It is engineered to meet the diverse needs of industrial control, intelligent equipment, Internet of Things (IoT) terminals and other embedded application scenarios, delivering reliable and efficient computing support for various professional fields.
With a streamlined trapezoidal profile, this single board computer not only features an innovative and space-saving design that fits perfectly into limited installation spaces such as narrow equipment cabinets and special-shaped devices but also enhances structural stability, effectively reducing the impact of vibration and external interference on the internal components during operation. The trapezoidal structure also facilitates heat dissipation, ensuring the device maintains stable performance even in harsh working environments.
In terms of core performance, the Trapezoidal SBC is equipped with high-performance processors (optional Intel® Elkhart Lake Atom® x6425E quad-core processor or equivalent), paired with high-speed DDR4 memory (up to 16GB) and large-capacity storage options (64GB eMMC, SATA Gen 3 slot and M.2 SSD support), enabling smooth operation of complex algorithms and multi-task processing. It supports multiple operating systems including Linux and Windows 10, providing flexible software compatibility for different application development needs.
The product is integrated with rich I/O interfaces and expansion options to meet diverse connection requirements. It comes with multiple Ethernet ports (10/100/1000Mbps), HDMI/DP/LVDS/eDP display interfaces, USB 2.0/3.0 ports, serial ports (RS232/RS422/RS485), and GPIO interfaces, allowing seamless connection with sensors, displays, printers, and other peripheral devices. Additionally, it supports Wi-Fi/BT/4G/5G expansion via M.2 slots, ensuring stable and uninterrupted communication in various network environments, which is ideal for IoT terminal applications that require long-distance data transmission.
Built with industrial-grade components and undergoing strict quality testing, the Trapezoidal Single Board Computer boasts excellent durability and reliability. It supports a wide operating temperature range of -40°C to +85°C, can withstand mechanical shock and vibration (complying with MIL-STD-202G standards), and has a relative humidity tolerance of 5%-95% (non-condensing). This makes it suitable for harsh industrial environments such as factories, construction sites, and outdoor facilities, with a long service life and low maintenance costs.
The product also features user-friendly design and easy deployment. It supports SDK for secondary development, allowing developers to customize functions according to specific project requirements, reducing development cycles and costs. The integrated PLC control system with a touch screen enables one-button operation, simplifying operation and reducing labor costs. It also comes with CE, RoHS, and other international certifications, ensuring compliance with global quality and environmental standards.
Whether used in industrial control systems, intelligent roofing/wall cladding equipment, IoT monitoring terminals, or embedded intelligent devices, the Trapezoidal Single Board Computer delivers stable, efficient, and flexible computing performance, becoming a reliable core component for various intelligent application scenarios. We also provide OEM/ODM services and 18-month warranty, as well as professional after-sales technical support, to meet the personalized needs of different customers.
♦ COMPANY PROFILE:
Hebei Xinnuo Roll Forming Machine Co., Ltd., not only produce different types of professional roll forming machines, but also develop intelligent automatic roll forming production lines, C&Z shape purline machines, highway guardrail roll forming machine lines, sandwich panel production lines, decking forming machines, light keel machines, shutter slat door forming machines, downpipe machines, gutter machines, etc.
Advantages of Roll Forming A Metal Part
There are several advantages of using roll forming for your projects:
- The roll forming process allows operations such as punching, notching, and welding to be performed in-line. Labor cost and time for secondary operations are reduced or eliminated, reducing part costs.
- Roll form tooling allows for a high degree of flexibility. A single set of roll form tools will make almost any length of the same cross-section. Multiple sets of tools for varying length parts are not required.
- It can provide better dimensional control than other competing metal forming processes.
- Repeatability is inherent in the process, allowing easier assembly of roll formed parts into your finished product, and minimizing problems due to “standard” tolerance build up.
- Roll forming is typically a higher speed process.
- Roll forming offers customers a superior surface finish. This makes roll forming an excellent option for decorative stainless steel parts or for parts requiring a finish such as anodizing or powder coating. Also, texture or pattern can be rolled into the surface during forming.
- Roll forming utilizes material more efficiently than other competing processes.
- Roll formed shapes can be developed with thinner walls than competing processes
Roll forming is a continuous process which converts sheet metal into an engineered shape using consecutive sets of mated rolls, each of which makes only incremental changes in the form. The sum of these small changes in form is a complex profile.
