Product Description of Arc Veneer Forming Machine

This automatic arc veneer forming machine is engineered for precise deformation of flat panels into curved veneers, integrating precision mold, compression forming mechanism and intelligent positioning adjustment system. It enables efficient, standardized batch production, replacing traditional manual/inefficient forming processes to significantly boost production efficiency and ensure consistent finished product quality. As core plate forming equipment, it is widely used in arc veneer processing across multiple industries.

Core Functions & Working Principle

Based on the plastic deformation principle of plates, the machine applies uniform pressure to flat veneers via the precise cooperation of compression forming mechanism and customized arc molds. Its high-precision positioning and adjustment system real-time controls forming radian and dimensional accuracy, avoiding deviation impacts on subsequent assembly. Equipped with an independent CNC control system, it supports flexible setting of arc radius, forming thickness and processing speed, with one-click process parameter recall for fast switching between multi-specification products and no frequent mold debugging needed.
To ensure forming stability, multiple limit rollers and pressing devices are configured to restrict plate displacement in all directions, preventing deviation, wrinkling and cracking. The formed arc veneers feature smooth inner arcs and flat outer arcs without edge bursting, requiring no secondary polishing and meeting direct assembly needs, which cuts process redundancy and material loss. Optional groove cutting function is available for integrated arc forming and groove processing, simplifying production procedures and eliminating additional cutting equipment investment.

Core Product Advantages

  1. Precise Forming & Reliable Quality

    Adopting absolute value four-axis control and high-precision sensors, the machine real-time monitors forming parameters with a forming accuracy of ±0.1mm, ensuring uniform radian and consistent size for batch-produced veneers and solving traditional forming’s deviation and inconsistency issues. Optional mold heating/high-frequency low-temperature hot pressing adapts to different material characteristics, enhancing shaping effect, preventing rebound deformation and extending product service life, ideal for wood and resin veneers and other easily deformable materials.

  2. High Efficiency, Energy Saving & Cost Reduction

    Driven by a variable frequency speed regulation motor with large torque and stable speed adjustment, the machine reaches a maximum processing speed of 8m/min, 5-8 times higher than manual operation, enabling thousands of pieces produced per shift. Optimized power structure and energy-saving motor reduce energy consumption by over 30% compared with traditional equipment; no lining or massive adhesive is needed, cutting material costs and reducing environmental pollution. Only 1-2 workers are required for operation, significantly lowering labor and management costs.

  3. Wide Adaptability & Flexible Operation

    The machine is compatible with various materials including solid wood veneer, density board, particleboard, resin board, aluminum profile veneer and color steel plate. It supports veneer thickness of 0.3-3.5mm (customizable) and arc radius adjustable from 50mm to 5000mm, meeting diverse processing needs of different industries and product specifications.6

  • Previous:
  • Next:

    • 微信图片_20220406094904 微信图片_202204060949041 微信图片_2022040609490423.png

    ♦ COMPANY PROFILE:

        Hebei Xinnuo Roll Forming Machine Co., Ltd., not only produce different types of professional roll forming machines, but also develop intelligent automatic roll forming production lines, C&Z shape purline machines, highway guardrail roll forming machine lines, sandwich panel production lines, decking forming machines, light keel machines, shutter slat door forming machines, downpipe machines, gutter machines, etc.

    Advantages of Roll Forming A Metal Part

    There are several advantages of using roll forming for your projects:

    • The roll forming process allows operations such as punching, notching, and welding to be performed in-line. Labor cost and time for secondary operations are reduced or eliminated, reducing part costs.
    • Roll form tooling allows for a high degree of flexibility. A single set of roll form tools will make almost any length of the same cross-section. Multiple sets of tools for varying length parts are not required.
    • It can provide better dimensional control than other competing metal forming processes.
    • Repeatability is inherent in the process, allowing easier assembly of roll formed parts into your finished product, and minimizing problems due to “standard” tolerance build up.
    • Roll forming is typically a higher speed process.
    • Roll forming offers customers a superior surface finish. This makes roll forming an excellent option for decorative stainless steel parts or for parts requiring a finish such as anodizing or powder coating. Also, texture or pattern can be rolled into the surface during forming.
    • Roll forming utilizes material more efficiently than other competing processes.
    • Roll formed shapes can be developed with thinner walls than competing processes

    Roll forming is a continuous process which converts sheet metal into an engineered shape using consecutive sets of mated rolls, each of which makes only incremental changes in the form. The sum of these small changes in form is a complex profile.
