Product Description of Arc Veneer Forming Machine
Core Functions & Working Principle
Core Product Advantages
-
Ultra-Precise Forming, Consistent Quality
Equipped with absolute value four-axis control technology and high-sensitivity sensors, the machine achieves full-process real-time monitoring of the forming process, with the forming accuracy strictly controlled within ±0.1mm. Every batch of arc veneers has uniform radian and consistent size, laying a solid foundation for enterprises to produce high-quality products. The optional hot pressing function can be flexibly adjusted according to material properties, effectively avoiding rebound deformation after forming, improving the shaping stability of veneers, and especially suitable for the processing of various easily deformable materials.
-
Efficient Production, Energy Saving & Environmental Protection
Powered by a high-quality variable frequency speed regulation motor, the machine has strong power, stable operation and adjustable speed, with a maximum processing speed of 8m/min, which is a qualitative leap in production efficiency compared with traditional manual processing (5-8 times higher). The optimized energy-saving design reduces energy consumption by more than 30%, and the forming process does not require a large number of adhesives and linings, which is both environmentally friendly and cost-saving. The high degree of automation only requires 1-2 operators, greatly reducing the enterprise’s labor input and management costs.
-
Strong Compatibility, Customizable Service
The machine has extremely wide material adaptability, and can process almost all common plate materials in the market such as solid wood, density board, aluminum profile and color steel plate. The standard processing range covers 0.3-3.5mm thickness and 50mm-5000mm arc radius, and all parameters can be fully customized according to the actual production needs of customers. We provide personalized mold customization and function matching services to meet the diverse processing needs of different industries and enterprises, and create exclusive forming solutions for customers.
♦ COMPANY PROFILE:
Hebei Xinnuo Roll Forming Machine Co., Ltd., not only produce different types of professional roll forming machines, but also develop intelligent automatic roll forming production lines, C&Z shape purline machines, highway guardrail roll forming machine lines, sandwich panel production lines, decking forming machines, light keel machines, shutter slat door forming machines, downpipe machines, gutter machines, etc.
Advantages of Roll Forming A Metal Part
There are several advantages of using roll forming for your projects:
- The roll forming process allows operations such as punching, notching, and welding to be performed in-line. Labor cost and time for secondary operations are reduced or eliminated, reducing part costs.
- Roll form tooling allows for a high degree of flexibility. A single set of roll form tools will make almost any length of the same cross-section. Multiple sets of tools for varying length parts are not required.
- It can provide better dimensional control than other competing metal forming processes.
- Repeatability is inherent in the process, allowing easier assembly of roll formed parts into your finished product, and minimizing problems due to “standard” tolerance build up.
- Roll forming is typically a higher speed process.
- Roll forming offers customers a superior surface finish. This makes roll forming an excellent option for decorative stainless steel parts or for parts requiring a finish such as anodizing or powder coating. Also, texture or pattern can be rolled into the surface during forming.
- Roll forming utilizes material more efficiently than other competing processes.
- Roll formed shapes can be developed with thinner walls than competing processes
Roll forming is a continuous process which converts sheet metal into an engineered shape using consecutive sets of mated rolls, each of which makes only incremental changes in the form. The sum of these small changes in form is a complex profile.
