Product Description of Arc Veneer Forming Machine
Core Functions & Working Principle
Core Product Advantages
-
Precise Forming, Controllable Quality
Adopting four-axis control and high-precision sensors, real-time monitoring forming parameters with ±0.1mm accuracy, ensuring uniform batch production. Optional mold heating/high-frequency hot pressing adapts to different materials, prevents rebound deformation, extends service life, and is suitable for easily deformable materials such as wood and resin veneers.
-
High Efficiency & Energy Saving, Cost Reduction
Driven by variable frequency motor, maximum speed 8m/min, 5-8 times higher than manual operation, thousands of pieces per shift. Optimized structure reduces energy consumption by over 30%; no lining/adhesive needed, cutting material costs. Only 1-2 workers are needed, lowering labor and management costs.
-
Wide Adaptability, Flexible Customization
Applicable to solid wood veneer, density board, aluminum profile, color steel plate and other materials. Supporting 0.3-3.5mm thickness (customizable) and 50-5000mm adjustable arc radius, it meets diverse processing needs of different specifications and industries.
♦ COMPANY PROFILE:
Hebei Xinnuo Roll Forming Machine Co., Ltd., not only produce different types of professional roll forming machines, but also develop intelligent automatic roll forming production lines, C&Z shape purline machines, highway guardrail roll forming machine lines, sandwich panel production lines, decking forming machines, light keel machines, shutter slat door forming machines, downpipe machines, gutter machines, etc.
Advantages of Roll Forming A Metal Part
There are several advantages of using roll forming for your projects:
- The roll forming process allows operations such as punching, notching, and welding to be performed in-line. Labor cost and time for secondary operations are reduced or eliminated, reducing part costs.
- Roll form tooling allows for a high degree of flexibility. A single set of roll form tools will make almost any length of the same cross-section. Multiple sets of tools for varying length parts are not required.
- It can provide better dimensional control than other competing metal forming processes.
- Repeatability is inherent in the process, allowing easier assembly of roll formed parts into your finished product, and minimizing problems due to “standard” tolerance build up.
- Roll forming is typically a higher speed process.
- Roll forming offers customers a superior surface finish. This makes roll forming an excellent option for decorative stainless steel parts or for parts requiring a finish such as anodizing or powder coating. Also, texture or pattern can be rolled into the surface during forming.
- Roll forming utilizes material more efficiently than other competing processes.
- Roll formed shapes can be developed with thinner walls than competing processes
Roll forming is a continuous process which converts sheet metal into an engineered shape using consecutive sets of mated rolls, each of which makes only incremental changes in the form. The sum of these small changes in form is a complex profile.
